    1560 Plasma Portable Cutting Machine With Steel Rail 1-30mm

    Ask Lasest Price
    Brand Name : YAOQIANG
    Model Number : CUT-1560
    Certification : CE ISO
    Price : US $1,200-1,600/ Piece
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100pcs/month
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    1560 Plasma Portable Cutting Machine With Steel Rail 1-30mm

    1560 CNC Portable Plasma Flame Cutter with Steel Rail


    The portable CNC plasma flame cutting machine is small in size, and the main equipment is made of 6063 hard aluminum alloy. It has good balance, light weight, small working inertia and beautiful appearance.


    Equipped with numerical control system, LGK series and American plasma sources are available, cutting thickness is 0.3-40mm, using flame cutter head can cut the maximum thickness of 200mm.


    This portable plasma cutting machine has extremely high program memory and storage configuration: it can store more than 1,000 drawings of complex cutting patterns.


    Load the designed cutting pattern drawings quickly and easily, avoid repeated input of the cutting pattern, save time and improve efficiency.


    Specification:

    Model1560
    Effective Cutting Width (X axis)1500mm
    Effective Cutting Length (Y axis)6000mm
    Cutting ModePlasma
    Plasma powerHuayuan 65A
    Cut thicknessPlasma 1-30mm; flaming 1-200mm
    Drive ModeLinear guide and rack gear
    CNC systemBeijing START CNC
    Plasma cutting speed1-18 m/min
    Speed setting error≤±5%
    Max running speed20m/min
    Torch height controller accuracy≤±1.0mm
    Longitudinal line accuracy±0.3mm/10mm
    MotorStepper motor and driver
    Electrical componentsSchneider
    Moving Precision0.01mm per step
    Power Source380V 50/60Hz
    Height controller(plasma)Starfire
    SoftwareFASTCAM software

    Working environment requirement

    Working temperature-5ºC-50ºC
    2.
    Relative humidity90% non-condensing
    3.
    SurroundingsVentilation, no impact within 5 meters
    4.
    Power supply voltage220V±5%, 380V±5%
    5.
    Power frequency50Hz
    6.
    input powerMachine tool 1KW
    7.
    Grounding typeCentralized direct

    Why Choose US?
    1. More than 10 years of production experience to ensure product quality and timely delivery.
    2. The perfect after-sales service team can solve all kinds of problems in time. You can communicate via email, phone, whatsapp, skype, wechat, etc.
    3. We are a manufacturer, have enough spare parts and consumables, and deliver them in time to solve your worries.
    4.Provide OEM/ODM Service.
