220V CNC Plasma Flame Cutting Machine

Ask Lasest Price
Brand Name :	YAOQIANG
Model Number :	CNC-CG4000
Price :	US $8,900-13,500/ Piece
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	20set/month
Delivery Time :	10 days

Add to Cart

Product Details
Company Profile

220V CNC Plasma Flame Cutting Machine

CNC Multi-Head Strip Flame Plasma Cutting Machine Gas Gantry Type Cutting Machine

The cutting machine uses imported AC motor, and driven with imported bevel gear reducer. With precision gear and rack move, to ensure stable function. Air cutting speed is adjusted by frequency transformer. The air source control box on the main engine can adjust air pressure from every tunnel easily. All the pressure adjusting valve and main air pipe are original imported. Pipe and wire on the broadwise cutting gun all use imported supporting chain, safe and neat.

model	Drive way	two rails' distance (mm)	effective cutting width (mm)	cutting thickness(mm)	cutting speed (mm/min)	max speed (mm/min)	cutting torch vertical route(mm)
CNCI-3000	single side	3000	2100	6-200	100-750	6000	150
CNCI-3500	single side	3500	2600			6000	150
CNCI-4000	single side	4000	3100			12000	150
CNCII-5000	double sides	5000	4100			12000	150
CNCII-6000	double sides	6000	5100			12000	150
CNCII-7000	double sides	7000	6100			12000	150
CNCII-8000	double sides	8000	7100			12000	150
CNCII-9000	double sides	9000	8100			12000	150
CNCII-10000	double sides	10000	9100			12000	150

Supply scope:
1,Frame unit: Beam, pipe, broadwise beam and longitude and broadwise reducer and etc.
2,Track unit: Guide and accessories. The guide size is 14m*2PCS.
3,Cutting gun unit: Linear single cutting gun*10PCS and accessories.
4,Electric control system: Electric control cabinet, longitude and broadwise motors and accessories.
5,Gas source unit: Main air rubber pipe, suspending sliding vehicle and etc.
6,Spare parts: 1 set

We would love to have you join the thousands that are already part of our YAOQIANG family.

Documents with goods:
1, Instructions including map of electricity and gas.
2, Certificate
3, Packing list
4, On site installation drawing for laying foundations.
