    1000mm 1500mm 2000mm 3 In 1 H Beam Welding Line

    Ask Lasest Price
    Brand Name : YAOQIANG
    Model Number : YQPJ
    Certification : CE ISO
    Price : US $35,000-45,000/ Piece
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30pcs/month
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    1000mm 1500mm 2000mm 3 In 1 H Beam Welding Line


    High efficiency CE Certificate 3in 1 H-Beam Assembly Machine with straightening and spot welding for h beam


    The main machine of the 3-in-1 H-beam integrated machine includes H-steel assembly, welding, straightening, roller conveyor, etc.
    Electrical system controlled by PLC program system, equipped with touch screen display light


    Technical Parameters

    Modelweb heightweb thicknesswelding and straightening speedflange widthflange thicknessoverall power
    YQPJ10001000mm6-16mm0.35-3m/min200-800mm6-20mm13.4kw
    YQPJ12001200mm6-16mm0.35-3m/min200-800mm6-20mm13.4kw
    YQPJ15001500mm6-16mm0.35-3m/min200-800mm6-20mm13.4kw

    MZ-1000/1250 SAW welding machine specification:

    No.Name
    1welderMZ-1000(optional,also can use CO2 welder)
    2
    Welding machine control box
    MZ-1000
    3
    Inverter manufacturers
    11KW,2.2KW HUICHUAN
    4
    Major electrical equipment manufacturers
    SIEMENS, OMRON (Japan)
    5Hydraulic parts manufacturersTAIWAN
    6main motor supplier
    NANTONG
    7Wing web centering motor2 sets NINGBO
    8Main reducer manufacturers
    CHANGZHOU
    9recovery equipment
    2 sets WUXI

    FAQ:

    1.Q:Are you a factory or trading company?
    A: We are a factory.


    2. Q:What are your payment terms?

    A: We support T/T, L/C, Western Union and so on. Other ways can also be received after we both sides discussion and agreement. Any other questions contact us directly!


    3. Q:How about the warranty?
    A: There are 12 months for the warranty.
    While the warranty is not responsible for those broken by violence


    4.Q:Where is your factory located? How can I visit there?
    A: Our factory is located in Jiangsu Wuxi(next to Shanghai),China.You can fly to Shanghai airport directly.All our clients, from home or abroad, are warmly welcome to visit us!
